FEATURES

• BASIC MACHINE

Having a stainless steel body and frame of body duly painted and provided with a stainless steel hopper having    a    vertical    stand,    an    electro-magnetic    vibratory    feeding    unit, cartridge    heaters,    horizontal    and  vertical  cutting  arrangements,  foil holders  with  arms,

1.0HP/1440RPM, 415V (or 385V)/TEFC motor, worm- reduction gear box and clutch, capable of handling a maximum foil width of 320mm.

The Control Panel will be fitted with ON/OFF switch, Vibrator Controller, display lamps & 2 nos. Electronic digital temperature controllers. Complete machine as mentioned above but without Change parts.

• STAINLESS STEEL COVER

The top as well as all four sides of the machine will be added with 3 mm stainless steel sheet of 304 grade.The machine doors, the cover of the vibrator, the control panel and power panel will be entirely fabricated out of stainless steel sheet of 304 grade.

• BASE FRAME FOR MACHINE

The entire machine will be mounted on a Profile-Frame fabricated out of mild steel channels. This frame will be provided with a detachable drip-tray for the collection of oil/grease drip. This will keep the floor under the machine clean and accessible at all times in keeping with GMP practices

• PRODUCT CONVEYOR

1.5 meter conveyor will be supplied along with the machine.

The direction of the conveyor will be left to right as viewed from the front.

• VARIABLE FREQUENCY DRIVE

One Variable Frequency Drive unit fitted inside the machine for varying the speed of this machine to suit the product being fed through the machine

• SERVO CUTTING UNIT

The machine will be fitted with a Servo rotary cutting mechanism to Provide horizontal zigzag cutting of the web

• CHANGE PARTS

One set of Change Parts to suit one spec ific strip-layout consistin

• ROLLERS

One pair of heat-sealing rollers each roller fitted with twin sliprings, back gears, cam-ring, clamps and a steners. There will be a PT-100 sensor embedded in the body of each roller; each sensor will be connected internally to the pair of sliprings on the roller.

• BOWEL

Stainless steel and alloy bowl feeder (for vibratory feeding)

• FEEDING CHUTE

Stainless steel chute-channel-release pin assembly of stainless steel.

MACHINE GUARDING

The machine will be fitted with a framework of aluminum extruded sections which will cover the front part of the machine and will enclos e the Foil Holders, the Heat-Sealing Rollers and the Horizontal and or rotary Cutter Assembly. The framework will then be fitted with clear Acrylic Plates of 8mm thickness. (The guarding will not be fitted with safety switches).
